Attenuators and Pulse Limiters
DGA 9552 N DGA 9552 N is a bidirectional attenuator, i.e. the attenuation and power capability specification is valid for both directions.There is a large variety of applications for this attenuator: The measuring range of a spectrum analyzer can be increased. Any kind of meter can be protected against overload; it can be used to […]
CDNE For Emission Measurement On Luminaries acc. EN 55015
CDNE M2 CDNE with tight tolerances for CISPR 15 emission measurements with 2 mains conductors can also be used as CDNE AF2. Datasheet CDNE M2 CA CDNE M2 Part A Part A of the calibration or short adapter for CDNE M2 CA CDNE Part B Part B of the calibration or short adapter for CDNE […]
Coaxial Cables
AK 9513 50 Ohm Coax. Cable with N plugsIndividual lengthUsable up to 3 (5) GHzIndiv. Cal. possible if cable longer than 3 mStandard lengths: 3 m, 5 m, 10 m Datasheet AK 9513 AK 9515 E 50 Ohm Coaxial Cable with N plugsLow lossGood flexibilityUsable up to 10 GHz10.8 mm diam.Indiv. Cal. possible if cable […]
Field Meters
VUFM 1670 E-Field Meter70 kHz-2.5 GHz1V/m-300V/mLinear Polarizedcharger ACS 110 required Datasheet VUFM 1670 VUFM 1671 LCD-Display Unit for VUFM 1670with 5 m fibre optical linkcharger ACS 110 required Datasheet VUFM 1671
Coupling Networks And Accessories For Immunity Tests
Coupling and Decoupling Networks CDNs for Immunity Testing (10 kHz to 400 MHz) Type Coupling / Feature CDN Coupling and decoupling networks for frequencies: 150 kHz – 230 MHz (IEC / EN 61000-4-6) CDG A 31xx Calibration adapter for CDNs, matching impedance 50/150 Ohm EMCL-20 EM coupling section for cable diameters up to 20 mm […]
Coupling Networks And Other Accesories For Surge Generators
Coupling Networks / Decoupling Networkst Grid Applications / 3-Phase Type Rated Current Coupling/Feature CWG 520 4 x 16 A Surge + Burst / Standard Connecting Cables / Only Surge Test 3-Phase CDN Type Rated Current Coupling to / Feature CWG 1525 1 A 2 cables unshielded, symmetrical / fieldbus CWG 1526-4 / 1526-10 2 x […]
Coupling Networks And Other Accessories For Burst Tests
CDN | Coupling / Decoupling Network Burst 3-Phase CDN Type Rated Current Characteristics CWG 520 3-phase CDN 4 x 16 A For burst and surge tests with burst generator SFT 2400 / 1400 / 1420 or surge generator CWG 2500 / 1500 CDN | Coupling / Decoupling Networks for Burst Function AXOS 5 / 8 […]
Conducted Interference Immunity HF/LF
Schlöder’s conducted interference immunity devices offer reliable and comprehensive solutions for testing the immunity of your systems to high-frequency and low-frequency disturbances. Whether for continuous or short-term disturbances, our products ensure compliance with global EMC standards and enhance the reliability of your electronic and electrical systems.
In operation, powerful components with high levels of interference and highly sensitive electronics are often operated close to one another. Voltage fluctuations or HF and LF signals should not cause any impairments, such as permanent or temporary malfunctions. During tests for conducted interference immunity, the test device’s immunity to such interference is assessed by coupling interference onto supply or signal lines.
Schloder Surge Generators
Schloder surge generators provide reliable and comprehensive testing solutions for high-energy interference pulses, ensuring compliance with global EMC standards and enhancing the durability and reliability of your electronic and electrical systems.
In operation, electronic and electrical devices, systems, and installations must not be impaired by surge voltages. Surge voltages, such as atmospheric discharges (lightning strikes), short circuits, or significant switching overvoltages (switching capacitor banks), involve currents in the kV / kA range and rise times in the microsecond range. These voltages can exhibit a broadband spectrum up to several MHz. During surge testing, these high-energy voltages are simulated by surge generators to test their impact on devices in accordance with IEC 61000-4-5.
Power Failure Generator VIS 1700
The VIS 1700 is a versatile tool for testing the robustness of devices against power interruptions and fluctuations, ensuring compliance with relevant standards and reliable performance in real-world scenarios.
Short-term voltage dips, interruptions, and fluctuations can affect electrical and electronic devices, potentially leading to functional issues or damage. The VIS 1700 mains interruption generator is designed to simulate these conditions according to the standards IEC 61000-4-11 (AC) and IEC 61000-4-29 (DC). It ensures that devices meet immunity requirements for AC and DC mains connections with input currents up to 16 A per conductor.
