Langer SX, Passive, Near Field Probes (1GHz up to 20 GHz)
The SX family consists of three H-field probes and one E-field probe.
The SX1 set (two H-field probes and one E-field probe) and the SX-R 20-1 set are available.
December 20, 2024
The SX family consists of three H-field probes and one E-field probe.
The SX1 set (two H-field probes and one E-field probe) and the SX-R 20-1 set are available.
The XF family consists of four magnetic-field probes and three E-field probes. The XF1 set (four magnetic-field probes and one E-field probe) as well as customized sets are available.
The RF family consists of nine magnetic field probes and six E-field probes, which are available in sets. These sets are optimized for different measurement tasks.
We are happy to create customized sets upon request.
The LF family consists of seven magnetic-field probes, four of which are included in our LF1 probe set. We are happy to create customized sets upon request.
FS-SET 7100 B Nearfield Probe Set including:• HFSL 7101 B Active Near Field Probe (magnetic), 9 kHz – 30 MHz• HFSH 7102 B Active Near Field Probe (magnetic), 4 MHz
FSH3D Isotropic H-Field Antenna for the Rohde und Schwarz handheld spectrum analyser FSH or the TS-EMF System. • 9 kHz – 200 (300) MHz• Light weight low attenuation radom• Outer
The Coupling- / Decoupling Networks are used to inject common mode disturbances to Equipment under Test (EuT). Further the CDNs provide sufficient decoupling between Auxiliary Equipment (AE) and disturbance signal. The requirements for CDN and their application are described in the standard IEC 61000-4-6 (Immunity to conducted disturbances, induced by radio-frequency fields). CDNs have a common mode impedance of 150 Ohm and are available for a multitude of cable types and connectors.
MagTest System System to test the immunity against magnetic fields acc. MIL-461 E, ISO 11452-8, EN 61000-4-8, SAE J551-17 etc. The system components will be individually configured for your requirements.
To ensure the reliability and compliance of electronic and electrical devices with international standards, magnetic field generators and analyzers are essential for simulating and analyzing magnetic fields. Below are detailed descriptions of our key products and their applications:
During operation, electronic and electrical devices, systems, and equipment should not be affected by electromagnetic phenomena. Burst testing assesses devices’ tolerance to voltage peaks with high repetition frequencies, high amplitude, short rise time, and low energy. Our burst generators allow you to test immunity to interference in accordance with IEC 61000-4-4 standards, from 125 kHz to 2 MHz, far beyond standard requirements.
