Handheld Direction Finder
HHDF 5110 A – Handheld Direction Finder The Handheld Direction Finder HHDF 5110 A was designed to locate radio transmitters in conjunction with a suitable portable receiver or spectrum analyser. Thanks to its robust structure, the HHDF 5110 A is suitable for outdoor use, even under harsh environmental conditions.Since the directional pattern in E-plane and […]
Active Antennas
EFS 9218 Active Electric Field Probe with Biconical Elements9 kHz – 300 MHz12 µV/m – 65 V/mconst. antenna factor typ. 46 dB/m high symmetrybuilt in rechargeable batteryThe switchable preamplifier improves the antenna factor to 20 dB/m. Datasheet Option:Opt. ACS 410: Automatic charger ACS 410 for EFS9218 EFS 9219 Active antenna holderhigh sensitivity (1 µV/m … […]
Van der Hoofden Test Head
VDHH 9502 Van der Hoofden test head with protection network and individual calibration of the network acc. IEC 62493:2015 or VDE 0848-493. DatasheetProgram for the calculation of F-factor acc. IEC 62493:2015Program for the calculation of F-factor (R&S format) acc. IEC 62493:2015
Collapsible or Open Conical Elements
BBAE 9179 Foldable elements for immunity for automotive applicationsoptimized for 1 m measurement distancemax. diameter 150 cm20 – 220 MHzsuitable for: VHBC 9133, VHBD 9134, VHBD 9134-4Some Baluns may need a mechanical modification! Datasheet BBFA 9146 BBFA 9146 foldable conical elements are large open conical elements with variable adjustable opening angle.To improve the antenna properties […]
Antenna Holders / Baluns
VHA 9103 B Holder / Balun without telescopic dipole elements (for use with Biconical BBA 9106, BBAL 9136, BBAK 9137, BBVK 9138, FBAB 9177) HFBA 9122 HF-VHF Broadband balun / holder (0.1) 0.15 – 300 (500) MHz especially to measure very high field strength for use with BBAL 9136, BBA 9106, BBAK 9137, BBVK 9138 BBVU 9135 or BBUK 9139 biconical elements required […]
Radiating Loops
FESP 5139 – Radiating Loop The magnetic, handheld coil FESP 5139 was designed to generate defined mag-netic fieldstrength in the frequency range from DC up to 5 (7) MHz. The main application is immunity testing against magnetic fields.Depending on the current source char-acteristics magnetic fields up to 360 A/m can be generated for a short […]
Helmholtz Coils
Helmholtz Coils Helmholtz-Coils are especially designed to generate precisely defined magnetic fields from DC to the upper end of the audio frequency range and beyond. The generated fields are in a strongly linear relation to the coil current. The field- strength can be calculated exactly by analytical (or numerical) methods, based on the coils’ geometry, […]
Passive Magnetic Antennas, TX-Loop Antennas
Passive Magnetic Antennas, RX-Loop Antennas Overview Passive Magnetic Antennas, TX-Loop Antennas HFRA 1356 The HFRA 1356 is a passive loop antenna which is matched to a resonance frequency of 13.56 MHz with typ. 350 kHz bandwidth (-3dB) The purpose of the antenna is to produce defined magnetic fields at 13.56 MHz efficiently, i.e. to test […]
RX-Loop Antennas, Passive Magnetic Antenna
Passive Magnetic Antennas, RX-Loop Antennas Overview Passive Magnetic Antennas, RX-Loop Antennas HFRAE 5160 Receiving VHF – UHF loop antennadiam. 50 mm2-300 MHzTransformer Datasheet HFRAE 5161 HF RX Loopdiam. 100 mm0.07 – 120 MHz1 turnTransformer Datasheet HFRAE 5162 VLF-HF RX Loopdiam. 250 mm0.05 – 30 MHz1 turn Datasheet HFRAE 5163 Passive magnetic loop antennadiam. 50 mm0.009 […]
Van Veen 3D Loop Antenna
CISPR 15 3-dimensional loop antenna van Veen HXYZ 9170 Loop Antenna System ( LAS )3-dimensional large loop antennadiam. 2 macc. EN 55015 / CISPR 15Socket and Coaxial switch recommended Datasheet HXYZ 9170 Sockel Socket and mounting equipment for large loop HXYZ 9170 Datasheet HXYZ 9170 Umschaltbox 3 in one coaxial switch for manual / remote […]
